Self-Operated Temperature Regulating Valve
Self-Operated Temperature Regulating Valve
Self-Operated Temperature Regulating Valve
Self-Operated Temperature Regulating Valve

Self-Operated Temperature Regulating Valve

  • Uses the medium’s own thermal energy for automatic temperature control; no external power supply needed
  • For automatic temperature control in heat exchangers handling hot/cold water, steam and oil; widely used in district heating systems
  • DN15-200, PN1.6/4.0 MPa; five adjustable temperature ranges from 0 °C to 270 °C; ±5 % control accuracy

Category

Overview

YZW self-operated temperature regulating valve consists mainly of a control valve and a temperature controller. Requiring no external energy source, it performs automatic regulation by relying on the temperature change of the controlled medium itself, making it an energy-saving product. It is mainly used for automatic temperature control in various heat exchangers handling hot and cold water, steam, oil and other media, and is widely applied in district heating and supply systems as well as other industrial fields.

The valve is available with nominal pressures of PN16 and PN40 (equivalent to 1.6 and 4.0 MPa) and nominal diameters from 15 to 200 mm. It provides temperature regulating ranges from 0 °C to 270 °C, and the valve body can withstand service temperatures up to 270 °C.

Main Parts Materials

Component Material Option 1 Material Option 2
Valve body ZG230-450 ZG1Cr18Ni9Ti
Valve seat ZG1Cr18Ni12Mo2Ti Cr18Ni12Mo2Ti
Valve plug 1Cr18Ni9Ti Cr18Ni12Mo2Ti
Bellows sleeve 1Cr18Ni9Ti Cr18Ni12Mo2Ti
Balancing bellows 1Cr18Ni9Ti
Temperature bulb H62 1Cr18Ni9Ti
Capillary tube H62 1Cr18Ni9Ti
Connector 35 1Cr18Ni9Ti

Control Valve Technical Parameters

Parameter Type Nominal Diameter DN (mm)
15 20 25 32 40 50 65 80 100 125 150 200
Nominal Pressure PN (MPa) 1.6, 4.0
Rated Flow Coefficient Kv Single-seat 5 7 11 20 30 48 75 120 190 300 480 760
Double-seat     12 22 33 53 83 132 209 330 528 836
Cage     11 20 30 48 75 120 190 300 480 760
Rated Stroke (mm) 6 6 8 8 10 14 14 20 20 20 35 35
Maximum Allowable Differential Pressure (MPa) 1.6 1.6 1.6 1.6 1.6 1.6 1.6 1.6 1.6 1.5 0.5 0.5
Temperature Regulating Range (°C) 0~70, 50~120, 100~170, 150~220, 200~270
Control Accuracy (%) ±5
Allowable Overload Temperature (°C) The upper limit of each corresponding temperature regulating range plus 50
Ambient Temperature (°C) -40 ~ +80
Installation Connector G1"
Capillary Tube Length (m) 3, 5, 8
Allowable Leakage Hard seat Single-seat: ≤ 10-4 × rated valve capacity (Class IV); double-seat and cage: ≤ 5 × 10-3 × rated valve capacity (Class II)
Soft seat (ml/min) 0.15 0.15 0.30 0.45 0.60 0.90 1.70 4.0 4.0 6.75 11.10 16.0
